BRTIRPZ2465A 四轴机器人

Name: BRTIRPZ2465A 四轴机器人
SKU: BRTIRPZ2465A
Availability: InStock

$71,000.00

【产品详情】
BRTIRPZ2465A是伯朗特机器人股份有限公司针对某些单调、频繁和重复的长时间作业，或是危险、恶劣环境下的作业等而开发的一款四轴立柱码垛机器人，实际码垛高度可达2.5m，其拥有2334mm臂展，最大负载65kg，超大的空间覆盖范围（可完全覆盖1.2m*1.2m及以内的所有规格托盘）。多自由度的灵活性，结构更为精简，维护方便，对上下料、搬运、拆包投料、拆垛、码垛等场景能够应对自如。
精度高——重复定位精度±0.15mm

【主要规格】
适用场景：码垛、拆垛
臂展：2334 mm
最大负载：65 kg
重复定位精度：±0.15 mm
功率：7.82 kVA
本体重量：693.5 kg

【规格参数表】
| 项目 | 范围 | 最大速度
| 手臂 | J1 | 2400mm | 660mm/s
| J2 | ±170° | 117°/s
| J3 | ±145° | 171°/s
| 手腕 | J4 | ±360° | 296°/s

Compare

Add to wishlist

SKU: BRTIRPZ2465A Category: 四轴机器人 Tag: 四轴机器人

Description

BRTIRPZ2465A is a four axis column palletizing robot developed by BORUNTE for certain monotonous, frequent, and repetitive long-term operations, or operations in dangerous and harsh environments. The actual palletizing height can reach 2.5m, with a 2334mm arm span and a maximum load of 65kg. It has a large space coverage range (can fully cover all sizes of pallets up to 1.2m * 1.2m). The flexibility of multiple degrees of freedom makes the structure more streamlined and easy to maintain. It can handle scenarios such as loading and unloading, handling, unpacking and feeding, unpacking and stacking with ease.
High precision, repeated positioning accuracy: ± 0.15mm
